JBL LINK VIEW

Details
Variations

JBL legendary sound in a Smart Display with the Google Assistant.

$269.00269.0 each $369.95 Save $101
Product Actions
Add to cart options
+

Back Order.

The expected in-stock date is 30 November 2018.



Legendary sound. Now in a Smart Display with the Google Assistant.

Get more than legendary sound. The integrated display included on JBL LINK VIEW allows you to get things done easily. It also has the Google Assistant built in, you can ask questions and tell it to do things. Just start with “Hey Google” to quickly enjoy your entertainment, stay connected with loved ones, view glanceable answers, manage daily tasks, and control your smart home. Your Assistant can help free up your hands and time, so you can focus on the things that matter most. Like watching videos of your favorite YouTube creators, reliving memories of your latest family vacation, making a video call to your best friend, receiving step-by-step baking instructions for delicious chocolate chip cookies, or dimming the lights for movie night. All this is delivered through a proprietary JBL transducer array, driven by a digital amplifier tuned to deliver full rich bass and crystal clear highs. This amazing combination of the Google Assistant, JBL Audio horsepower and HD display make JBL LINK VIEW a must have for your home or office. Google, Google Photos, Google Duo, YouTube and other related marks are trademarks of Google LLC.

Item# JBLLINKVIEWBLKAS

General Specifications

Transducer 2 x 51mm (2”) full range driver
Output power 2 x 10W RMS
5MP front facing camera Yes
8” HD touch screen Yes
2.4G Wi-Fi transmitter frequency range 2412 – 2472MHz (2.4GHz ISM Band, USA 11 Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power <20dBm (EIRP)
2.4G Wi-Fi modulation OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM, 64QAM
5G Wi-Fi transmitter power <20dBm (EIRP)
5G Wi-Fi modulation OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM, 64QAM, 256QAM
5G Wi-Fi transmitter frequency range 5.15 - 5.35GHz, 5.470 - 5.725GHz, 5.725 - 5.825GHz
Gross Weight 1.9kg
Net Weight 1.3kg

Audio Specifications

Frequency response 60Hz-20kHz (-6dB)
Signal-to-noise ratio >80dBA

Dimensions

Dimensions (W x H x D) 332 x 152 x 100mm

Control and Connection Specifications

Bluetooth version 4.2
Bluetooth transmitter frequency range 2402 – 2480MHz
Bluetooth transmitter power ≤10dBm (EIRP)
Bluetooth transmitter modulation GFSK, π/4 DQPSK, 8DPSK
Wireless network 802.11b/g/n/ac (2.4GHz/5GHz)

Powering Input

Power Supply 100-240V~50/60Hz
Click here for a complete list of all specs for this product

Spec Sheet (EN)

English 2 MB
  • 1 x JBL LINK VIEW
  • 1 x Power cable
  • 1 x Quick start guide
  • 1 x Warranty card
